ATMega32-PU 8-Bit AVR RISC-based Microcontroller Dip
The ATmega32 (specifically the ATmega32A) is a high-performance, low-power 8-bit microcontroller based on the Atmel AVR enhanced RISC architecture. It is designed to be a highly flexible and cost-effective solution for embedded control applications by combining an 8-bit RISC CPU with In-System Self-Programmable Flash memory on a single chip.
Features
| ATMEGA32 – Simplified Features | |
| CPU | 8-bit AVR |
| Number of Pins | 40 |
| Operating Voltage (V) | +2.7 to +5.5 V (+5.5V being absolute maximum) |
| Number of I/O pins | 32 |
| Communication Interface | JTAG Interface(24,25,26,27 PINS)
Master/Slave SPI Serial Interface(5,6,7,8 PINS) Programmable Serial USART(14,15 PINS) Two-wire Serial Interface(22,23 PINS) |
| ADC Module | 8 channels , 10-bit resolution ADC |
| Timer Module | Two 8-bit counters, One 16-bit counter [Total three] |
| Analog Comparators | 1 |
| DAC Module | Nil |
| PWM channels | 4 |
| External Oscillator | 0-16MHz |
| Program Memory Type | Flash |
| Program Memory (KB) | 32Kbytes[10000 write/erase cycles] |
| CPU Speed (MIPS) | 16 MIPS |
| RAM Bytes | 2KBytes |
| Data EEPROM | 1024 Bytes |
| Watchdog Timer | Programmable Watchdog Timer with Separate On-chip Oscillator |
| Power Save Modes | Six Modes[Idle, ADC Noise Reduction, Power-save, Power-down, Standby and Extended Standby] |
| Operating Temperature | -55°C to +125°C(+125 being absolute maximum, -55 being absolute minimum) |
</td>
<td>Pin 0 of PORTB</td>
<td>T0( Timer0 External Counter Input) </p>
<p>XCK ( USART External Clock I/O)</td>
</tr>
<tr>
<td>2</td>
<td>PB1(T1)</td>
<td>Pin 1 of PORTB</td>
<td>T1(Timer1 External Counter Input)</td>
</tr>
<tr>
<td>3</td>
<td>PB2(INT2/AIN0)</td>
<td>Pin 2 of PORTB</td>
<td>AIN0(Analog Comparator Positive I/P) </p>
<p>INT2( External Interrupt 2 Input)</td>
</tr>
<tr>
<td>4</td>
<td>PB3(OC0/AIN1)</td>
<td>Pin 3 of PORTB</td>
<td>AIN1(Analog Comparator Negative I/P) </p>
<p>OC0 (Timer0 Output Compare Match Output)</td>
</tr>
<tr>
<td>5</td>
<td>PB4(SS)</td>
<td>Pin 4 of PORTB</td>
<td>SS (SPI Slave Select Input). This pin is low when controller acts as slave. </p>
<p>[Serial Peripheral Interface (SPI) for programming]</td>
</tr>
<tr>
<td>6</td>
<td>PB5(MOSI)</td>
<td>Pin 5 of PORTB</td>
<td> MOSI (Master Output Slave Input). When controller acts as slave, the data is received by this pin. </p>
<p>[Serial Peripheral Interface (SPI) for programming]</td>
</tr>
<tr>
<td>7</td>
<td>PB6(MISO)</td>
<td>Pin 6 of PORTB</td>
<td> MISO (Master Input Slave Output). When controller acts as slave, the data is sent to master by this controller through this pin. </p>
<p>[Serial Peripheral Interface (SPI) for programming]</td>
</tr>
<tr>
<td>8</td>
<td>PB7(SCK)</td>
<td>Pin 7 of PORTB</td>
<td> SCK (SPI Bus Serial Clock). This is the clock shared between this controller and other system for accurate data transfer. </p>
<p>[Serial Peripheral Interface (SPI) for programming]</td>
</tr>
<tr>
<td>9</td>
<td>RESET</td>
<td>Reset Pin, Active Low Reset</td>
<td>Pulled HIGH to RESET controller.</td>
</tr>
<tr>
<td>10</td>
<td>Vcc</td>
<td>Vcc = +5V</td>
<td></td>
</tr>
<tr>
<td>11</td>
<td>GND</td>
<td>GROUND</td>
<td></td>
</tr>
<tr>
<td>12</td>
<td>XTAL2</td>
<td>Connected to Crystal Oscillator</td>
<td></td>
</tr>
<tr>
<td>13</td>
<td>XTAL1</td>
<td>Connected to Crystal Oscillator</td>
<td></td>
</tr>
<tr>
<td>14</td>
<td>PD0(RXD)</td>
<td>Pin 0 of PORTD</td>
<td>RXD (USART Input Pin) </p>
<p>USART Serial Communication Interface</p>
<p>[Can be used for programming]</td>
</tr>
<tr>
<td>15</td>
<td>PD1(TXD)</td>
<td>Pin 1 of PORTD</td>
<td>TXD (USART Output Pin) </p>
<p>USART Serial Communication Interface</p>
<p>[Can be used for programming]</td>
</tr>
<tr>
<td>16</td>
<td>PD2(INT0)</td>
<td>Pin 2 of PORTD</td>
<td>External Interrupt INT0</td>
</tr>
<tr>
<td>17</td>
<td>PD3(INT1)</td>
<td>Pin 3 of PORTD</td>
<td>External Interrupt INT1</td>
</tr>
<tr>
<td>18</td>
<td>PD4(OC1B)</td>
<td>Pin 4 of PORTD</td>
<td rowspan=)
PWM Channel Outputs
19
PD5(OC1A)
Pin 5 of PORTD
20
PD6(ICP)
Pin 6 of PORTD
Timer/Counter1 Input Capture Pin
21
PD7 (OC2)
Pin 7 of PORTD
Timer/Counter2 Output Compare Match Output
22
PC0 (SCL)
Pin 0 of PORTC
TWI Interface
23
PC1 (SDA)
Pin 1 of PORTC
24
PC2 (TCK)
Pin 2 of PORTC
JTAG Interface
25
PC3 (TMS)
Pin 3 of PORTC
26
PC4 (TDO)
Pin 4 of PORTC
27
PC5 (TDI)
Pin 5 of PORTC
28
PC6 (TOSC1)
Pin 6 of PORTC
Timer Oscillator Pin 1
29
PC7 (TOSC2)
Pin 7 of PORTC
Timer Oscillator Pin 2
30
AVcc
Vcc for Internal ADC Converter
31
GND
GROUND
32
AREF
Analog Reference Pin for ADC
33
PA7 (ADC7)
Pin 7 of PORTA
ADC (Analog to Digital Converter) Channel 7
34
PA6 (ADC6)
Pin 6 of PORTA
ADC (Analog to Digital Converter) Channel 6
35
PA5 (ADC5)
Pin 5 of PORTA
ADC (Analog to Digital Converter) Channel 5
36
PA4 (ADC4)
Pin 4 of PORTA
ADC (Analog to Digital Converter) Channel 4
37
PA3 (ADC3)
Pin 3 of PORTA
ADC (Analog to Digital Converter) Channel 3
38
PA2 (ADC2)
Pin 2 of PORTA
ADC (Analog to Digital Converter) Channel 2
39
PA1 (ADC1)
Pin 1 of PORTA
ADC (Analog to Digital Converter) Channel 1
40
PA0 (ADC0)
Pin 0 of PORTA
ADC (Analog to Digital Converter) Channel 0
Where to Use ATMEGA32
ATMEGA32 is easy to program AVR controller. With appreciable program memory it can satisfy most EMBEDDED SYSTEMS. With various sleep modes it can work on MOBILE EMBEDDED SYSTEMS. Along with 32 programmable Input/Output pins, it can interface many peripherals easily. With Watchdog timer to reset under error it can be used on systems with no human interference. With so many features with each appreciating other we can implement ATMEGA32 in many control systems.
How to Use ATMEGA32
Using ATMEGA32 is similar to any other microcontroller. Similar to them it is not Plug and Play digital ICs. For working of ATMEGA32, first we need to save the appropriate program file in the ATMEGA32 FLASH memory. After dumping this program code, the controller executes this code to create the response.
Entire process of using an ATMEGA32 goes like this:
- List the functions to be executed by ATMEGA32
- write the functions in IDE programs using relative language
(Usually Atmel Studio 6.2 for Windows7,
Atmel Studio 7 for Windows10
(For these IDE the functions should be written in ‘C’ language)
- After writing the desired program compile for error elimination using IDE.
- Opt the IDE application to generate HEX file for the written program.
- Choose the programming device (usually SPI programmer made for AVR controllers) which establishes communication between PC and ATMEGA32
- Run the HEX file dumping software which is related to the chosen programming device.
- Choose the appropriate program HEX file in the SPI or other programmer software.
- Burn the HEX file of program in ATMEGA32 flash memory using this program.
- Disconnect the programmer, connect the appropriate peripherals for the controller and power the sytem.
Applications
There are thousands of applications for ATMEGA32.
- Temperature control systems
- Analog signal measuring and manipulations.
- Embedded systems like coffee machine, vending machine.
- Motor control systems.
- Digital signal processing.
- Peripheral Interface system.
